VW 1500 & 1600 Type 3, 1963-1973 (Haynes Repair Manual) by Haynes $24.95

(size chart)

For 1963-1973 Type III models with 91.1 cu in (1493 cc) and 96.7 cu in (1584 cc) engines.

View sample pages

Table of Contents

  • Introduction and routine maintenance
  • Chapter 1: Engine and cooling system
  • Chapter 2: Exhaust system, heat exchangers, heating and ventilation systems
  • Chapter 3: Fuel system
  • Chapter 4: Ignition system
  • Chapter 5: Clutch
  • Chapter 6: Transmission and final drive
  • Chapter 7: Automatic transmission
  • Chapter 8: Drive shafts – swing axle and double joint axle
  • Chapter 9: Braking system
  • Chapter 10: Electrical system and wiring diagrams
  • Chapter 11: Suspension, dampers and steering
  • Chapter 12: Bodywork and floor frame
